Chris Everest
Environments are elastic and we need total automation.
App Instances | 50 |
Prod Databases | 8 |
Environments | 3 | |
App Instances | (3x50) | 150 |
Databases | (3x8) | 24 |
Testing Apps | (8x50) | 400 |
Vagrant Apps | (50x50) | 2500 |
Databases | (8x8) + (8x50) | <eek> |
class { 'postgresql::server': }
postgresql::server::db { 'covermymeds':
user => 'cmm_user',
password => postgresql_password('cmm_user', 'supersecret '),
}
# Create the Role
postgresql::server::role { 'app_user': }
password_hash => postgresql_password('app_user', 'secret'),
}
# Apply GRANTS
postgresql::server::database_grant {'app_user':
privilege => 'ALL',
db => 'covermymeds',
role => 'app_user',
}
(...sigh)
Puppet makes this all super easy, we just have to look deeper. - Separate the config steps into workable, repeatable pieces. - Server Config, Roles, Databases and Permissions - Hieradata for structured yaml config - Extreme patience The secret sauce is Puppet Lab's custom resource type.
postgresql_psql { "unique_name":
command => 'ANY COMMAND THAT PSQL SUPPORTS',
db => 'DATABASE TO ACT ON',
unless => 'SQL COMMAND TO CHECK IF ACTION WAS ALREADY TAKEN',
require => Class['postgresql::server']
}
Wait... hiera what?
We set up two data structures for hiera
Define this data structure at the host level, so the app list can be moved around to different database clusters. Define this on our master only.
# DB Cluster to Application Mapping
cmm_pgsql::dblist::cluster1:
mydatabase:
apps:
- myapp1
- myapp2
- myapp3
# Equivilant to a hash of arrays
$myhash = hiera('cmm_pgsql::dblist::cluster1')
# yields => {
# 'mydatabase' => {
# 'apps' => [
# 'myapp1',
# 'myapp2',
# 'myapp3',
# ],
# },
#}
Define this data structure at the environment or common level. Any other puppet module can benefit from access to database credentials. Use this data structure for both PostgreSQL builds and to provide database configs to applications.
# Application to Role Mapping
app::dbconfig::myapp1:
mydatabase:
write_handle:
default_handle: true
role: default_write
host: vip-cluster1
database: mydatabase
adapter: postgres
username: myapp1_user
password: password
# Equivalent to a hash of arrays
$myhash = hiera('cmm_pgsql::dbconfig::myapp1')
# yields => {
# 'mydatabase' => {
# 'write_handle' => {
# 'default_handle' => true,
# 'role' => 'default_write',
# 'host' => 'vip-cluster1',
# 'database' => 'mydatabase',
# 'adapter' => 'postgres',
# 'username' => 'myapp1_user',
# 'password' => 'password',
# },
# },
#}
The meat and potatoes of our database infrastructure
https://github.com/covermymeds/cmm_pgsqlThe main class determines master vs. slave and failover status. Masters do everything, slaves do almost nothing (they're read only). Hosts in failover do absolutely nothing.
Statuses are determined by lib/facter/pg_replication.rb
Base setup will install requirements like SSL keys for client connections, other supporting packages (pg_top, pg_repack, etc), Postgres configuration and Shinken (nagios) Monitors. Masters and slaves alike get base setup configuration.
# Define any valid pg config value
cmm_pgsql::config:
'hot_standby_feedback':
value: 'on'
'ssl':
value: 'on'
'hot_standby':
value: 'on'
'max_connections':
value: '100'
'shared_buffers':
value: '1024MB'
'effective_cache_size':
value: '3072MB'
'checkpoint_segments':
value: '32'
'checkpoint_completion_target':
value: '0.9'
'default_statistics_target':
value: '100'
'work_mem':
value: '16MB'
This class performs setup of master related tasks.
At this point, creation of application credentials is started with a lookup of cmm_pgsql::dblist::<cluster>
From manifests/master.pp
calls to appdb { 'db1': ['app1', 'app2', 'app3'] }
will generate a single database creation.
After the database is created, it then makes calls to manifests/dbhandle.pp
for each app using that database.
The dbhandle type is essentially a hackzor (see dirty little secrets
) to link the database creation with the application credentials.
This takes the name parameter and allows unique creation of the db role credentials by splitting on a pre-concatenated resource name.
Finally, the PostgreSQL roles are created and permissions are satisfied with SQL Grant templates. This is very powerful, yet simple to implement.
# Create a unique resource name
$role_grants = "role:${role} ${username}@${database}"
# Only define the role if it doesn't exist
unless defined(Postgresql_psql[$role_grants]) {
postgresql_psql { $role_grants:
command => template("cmm_pgsql/grants/${role}.sql.erb"),
db => $database,
psql_user => $::postgresql::server::user,
psql_group => $::postgresql::server::group,
psql_path => $::postgresql::server::psql_path,
unless => "SELECT nspname, defaclobjtype, defaclacl
FROM pg_default_acl a
JOIN pg_namespace b ON a.defaclnamespace=b.oid
WHERE defaclobjtype = 'r'
AND aclcontains(defaclacl, '\"${username}\"=r/postgres')",
require => Postgresql::Server::Role[$username],
}
}
Leverage the postgresql_psql
resource once again to apply grants. Passing in a template, the list of
Grants will execute against our database.
# Template of grants, with username substituted
GRANT select, insert, update, delete ON ALL TABLES IN SCHEMA public
TO "<%= @username %>";
GRANT execute ON ALL functions IN SCHEMA public
TO "<%= @username %>";
GRANT USAGE ON ALL sequences IN SCHEMA public
TO "<%= @username %>";
ALTER DEFAULT PRIVILEGES IN SCHEMA public
GRANT select, insert, update, delete
ON TABLES TO "<%= @username %>";
ALTER DEFAULT PRIVILEGES IN SCHEMA public
GRANT execute ON functions to "<%= @username %>";
ALTER DEFAULT PRIVILEGES IN SCHEMA public
GRANT usage ON sequences to "<%= @username %>";
Remember the 'unless' parameter? This allows a simplified method of permission verification
# Determine if role permissions have been applied
SELECT nspname, defaclobjtype, defaclacl
FROM pg_default_acl a
JOIN pg_namespace b ON a.defaclnamespace=b.oid
WHERE defaclobjtype = 'r'
AND aclcontains(defaclacl, '"username"=r/postgres')
## Output
nspname | defaclobjtype | defaclacl
---------+---------------+---------------------------------------------
public | r | {username=r/postgres,username=arwd/postgres}
(1 row)
prefix_keys()
function allows us to uniquify data structures. Credit: competa.com
